Code rolling oil
Primary Performance Features
• Provides extreme lubricity, sharply reducing roll wear, energy draw and post-rolling hot scratches.
• Maintains outstanding mill cleanliness and anneal cleanliness; eliminate edge-carbon formation.
• Maximises zinc-layer adhesion on hot-dip galvanised strip.
• Extends emulsion life and cuts oil consumption to 0.1–0.3 kg t⁻¹ of rolled steel.
Target Process Results
• Steel surface free of oil stains and annealing edge-carbon.
• Post-rolling reflectance ≥ 75 %; total residual oil + Fe < 200 mg m⁻².
• Post-anneal surface carbon < 4 mg m⁻²; reflectance > 90 %; no stains or carbon edges.
• 100 % zinc adhesion after NH₃-atmosphere anneal & hot-dip galvanising.
• Emulsion iron fines ≤ 130 mg L⁻¹; ash ≤ 200 mg L⁻¹.
Rolling Oil (Neat) | HH-560 | Emulsion in Use | HH-560 |
Appearance: | clear, oily liquid | Concentration% | 1.5-2.5 |
Acid value | 4-7 | Free acid | 3-12 |
Saponification value | ≥190 | Saponification value | ≥170 |
Kinematic viscosity | 55-70 | ESI（4h） | 0.1-0.7 |
ESI | 0.1-0.7 | Fe content,,mg/ | ≤150 |
Flash point °C | ≥³210 | Ash content,mg/L | ≤250 |
Viscosity index | ≥³110 | PH | 5.8-6.5 |
PH | 6.0 | Temperature, ℃ | 45-58 |
